Green ADA Compliant Metal Mesh Picnic Table with Drainage Design

No.TB12 Commercial Metal Mesh Picnic Table with Thermoplastic Coating
No.: TB12
Brand: Arlau
Seats: 2 seats, 3 seats, 4 seats are available
Table: 81"L x 63.5"W x 30.5"H
Weight: Portable Mount: 220 lbs.
Seat: 38.5"L x 11.5"W x 18"H x 2" Thick
Weight: 225 lbs.
Table Top: 46"D x 30.5"H x 2" Thick
Space Between Seats: 15"
Tabletop: 2.5-3.0mm metal mesh or steel plate perforation
Bracket: φ42*2.5mm welded pipe
Steel surface treatment: thermoplastic coating, bracket powder coating
Powder coating: DuPont outdoor powder
Accessories: 304 stainless steel screws
Installation: optional embedded or expansion screw fixation
Scope of use: suitable for outdoor environments such as gardens, parks, scenic spots, schools, and city streets.
  • Green ADA Compliant Metal Mesh Picnic Table with Drainage Design
  • Green ADA Compliant Metal Mesh Picnic Table with Drainage Design
  • Green ADA Compliant Metal Mesh Picnic Table with Drainage Design
  • Green ADA Compliant Metal Mesh Picnic Table with Drainage Design
  • Green ADA Compliant Metal Mesh Picnic Table with Drainage Design
  • Green ADA Compliant Metal Mesh Picnic Table with Drainage Design
  • Green ADA Compliant Metal Mesh Picnic Table with Drainage Design
  • Green ADA Compliant Metal Mesh Picnic Table with Drainage Design

Description

Product Overview

Green, round and built around an open side, this accessible picnic table has a perforated steel top with two curved seats attached to a black tubular frame. The tabletop and the seats are both perforated and both carry the same smooth green thermoplastic coating, so water runs straight through instead of pooling on the surface people eat from. This 46 inch picnic table is a round steel unit for ground that has to work for everybody: park lawns, campus quadrangles, campground pads, clinic gardens, plaza corners. The top sits at dining height, and the gap between the two seats leaves room for someone to sit close to a wheelchair user rather than opposite them. A centre opening through the tabletop takes a parasol pole when a site needs shade. Green coating on the top and seats, black powder coat on the frame, nothing else on show. - Municipal parks and recreation grounds. A line of tables along a path or a ring around a playground, each one meeting accessibility expectations without a maintenance programme attached. The picnic table sits on a standard picnic pad and leaves the lawn around it free. - School and university campuses. Quadrangles, courtyards and waiting areas where students eat between classes. The open bay means a student in a wheelchair joins the same table as everyone else rather than using a separate one at the edge. - Healthcare facilities and senior communities. Garden seating outside a clinic, a care home or a therapy unit, where the seat height, the curved seat profile and a dry surface matter more than they do on a sports field. - Campgrounds and trailheads. Sites where tables stay out all season under trees. A heavy duty picnic table that sheds rain and debris is the difference between a usable picnic spot and a muddy one after a storm. - Corporate and government building grounds. Courtyard and forecourt seating that looks deliberate rather than improvised, in a green that sits comfortably against planting and stone. - Villa and residential community amenities. Shared garden and poolside seating for residents, where a picnic table with bench seating that stays clean and never needs repainting is what the management company is actually buying.

Frame, Mesh & Coating Build

  • Perforated steel top and seats. Tabletop and seat panels are formed from steel, perforated so the surface is more opening than plate. Thicker sheet than a light park table carries, which is what keeps the top flat instead of drumming under a full picnic basket. - Welded steel pipe frame. The pipe is cut, welded and dressed before coating — the reason this round steel picnic table stays rigid when a group leans on one side. A bolt-together frame is cheaper to ship and the first thing to work loose on a busy site. - Two coatings doing different jobs. The top and seats get the thermoplastic layer: thick, fused to the steel, non-porous. The frame gets a black DuPont outdoor powder coat. Hands and clothing touch the thermoplastic; the frame simply has to stay black and hard. - A sealed surface with no repainting cycle. Because the coating is the finish, there is no paint layer to chalk, flake or touch up. The maintenance schedule is washing, not recoating. - Built as an all weather outdoor picnic table. It is designed to be left out through sun, rain and snow rather than stored, which is the only way public seating is ever actually used. - Anti-slip feet on a stable footprint. The feet grip a slab or pad, so the table does not walk across the paving when people push back from it. The coating is the reason maintenance is short. A non-porous thermoplastic surface does not absorb spills, does not need sealing and does not need repainting, so the routine is washing rather than restoring. Everyday cleaning Rinse the top and seats with water and a mild household cleaner and let them air dry — the perforations do most of the work. Bird droppings, tree sap and food residue come off with a cloth. For stubborn grime on the tops and seats a power washer is fine; keep the nozzle moving and do not hold it against a coating edge. What to avoid Cleaners containing acetone should not touch any coated surface. Abrasive pads and wire brushes will dull the finish without making it rust, which is a pointless trade. Through the seasons The mesh does not trap meltwater, so there is no ice pocket to split the top and the table does not need covering over winter. After a hard freeze-thaw cycle, walk the site and check that the mounting bolts are still snug, and use a plastic shovel edge rather than a metal one when clearing snow off the tops. The annual check Once a year, go round the unit: seat screws, mounting bolts and the frame welds. Tighten anything that has worked loose and note anything that looks unusual. That is the whole schedule — one person with a hose and a spanner can keep a run of thirty tables in service. - Perforated and formed in one plant. Tabletop and seat panels are pierced and formed from steel into the round top, so the opening pattern lines up across the top instead of being pieced together from mismatched offcuts. - Welded, then dressed. The steel pipe frame is welded into one rigid assembly and cleaned up before coating, which is what keeps the seats and the table legs in the same plane once the unit is on site. - Coated in-house. The thermoplastic layer on the top and seats and the black DuPont powder coat on the frame are both applied before the unit is packed. Nothing goes out for finishing, so colour and build stay under one specification. - Stainless hardware, bagged per unit. Screws, seat fixings and mounting hardware travel with the instructions so the install crew is not hunting for parts. - A heavy duty picnic table by construction, not by label. The weight comes from the pipe wall and the sheet thickness. There is no added ballast and nothing decorative about the build. - Checked before it is crated. Coating coverage, weld quality, seat alignment and hardware count are verified on each unit before packing. - One manufacturer, one specification. Because we are a commercial picnic table manufacturer running our own coating line, a change of colour, seat count or top pattern is an instruction to production rather than a negotiation with a third party.
Green ADA Compliant Metal Mesh Picnic Table with Drainage DesignGreen ADA Compliant Metal Mesh Picnic Table with Drainage Design

Certified Quality & Environmental Systems

Three management-system certifications sit behind production, and each answers a different question you will eventually ask. ISO9001 covers quality management: documented procedures, defined inspection points and a process that can be traced from order through to dispatch. For your approval process, it is the difference between an outdoor picnic table supplier that can be approved on paper and one that has to be argued for. ISO14001 covers environmental management, including how steel waste and coating materials are handled in the plant. ISO45001 covers occupational health and safety — the standard that matters in a factory where steel is cut, welded, perforated and coated. Our products also meet CE requirements, giving European customers a conformity reference to file with the project paperwork. Ask our team for current certificate copies to attach to your submission — they are issued in the company name and dated, so check that the version on file matches the year your project requires.

Drainage & Wet-Weather Performance

The tabletop and the seats are formed in perforated steel, and that single decision governs how the whole table behaves in bad weather. Rain passes through the surface instead of sheeting across it, so a 46 inch picnic table that has stood out overnight is ready to eat at long before a solid-top one is.

What the openings do

There is no rim to trap a pool in the middle of the top, and no flat seat holding a film of water. Wet leaves, sand and grit drop through or wash off rather than collecting in a corner nobody can reach with a cloth. Nothing stands long enough for algae and mould to establish, which is the difference between a weekly wipe-down and a scrubbing job on a site with thirty tables. A dry seat is a safer seat too: someone stepping up or transferring from a chair is not putting their weight on a slick surface.

Where it matters most

Campsites and trailheads, where tables sit under trees and stay damp for days. Coastal sites with salt spray and frequent rain. Shaded courtyards and gardens with irrigation overspray. Wherever staff have to travel between furniture clusters, the value of a table that dries itself is measured in visits not made.

The green thermoplastic coating seals the steel and the perforations do the draining. The two work together to make this an all weather outdoor picnic table — one keeps the weather out of the metal, the other keeps it off the surface.

Green ADA Compliant Metal Mesh Picnic Table with Drainage DesignGreen round metal picnic table with attached curved seats and black frame

Wheelchair Access & Universal Seating

  • An open bay, not a closed ring. A conventional picnic table with bench seating boxes the tabletop in on every side. This one is laid out so that one bay of the round top stays completely clear, letting a wheelchair roll in under the table edge instead of parking alongside it.
  • Knee clearance under a 30.5-inch top. The underside is open and the legs sit at the ends of the unit rather than across the middle, leaving the space a footrest and a pair of knees actually need.
  • Room to approach and transfer. The clear bay gives somewhere to position a chair, and for users who prefer to transfer onto a seat, the seat end nearest the opening is the natural one to use.
  • 15 inches between seats. A companion can take the seat closest to the open bay without crowding it, so a couple or a family eats together rather than the wheelchair user sitting off to one side.
  • Seats at 18 inches, gently curved. A 2-inch thick seat at 18 inches suits older users and children as well as adults, and the curve keeps people from sliding toward the table edge.
  • Surfaces that stay usable when wet. Every seating surface is perforated, so on this metal picnic table a seat that has caught rain drains and dries rather than leaving a puddle where someone has to sit.
  • Dimensions you can put in front of an approvals board. 46-inch top, 30.5-inch table height, 15-inch seat gap, and an 81 x 63.5-inch overall footprint. Compare them against the accessibility requirements your authority enforces before the layout is signed off, and send them to us if you would like them checked against your project schedule.

Umbrella & Shade Options

  • Through the middle of the round top. This picnic table with bench seating has a centre opening that takes a parasol pole, so the canopy sits over the middle of the table where people eat rather than off to one side. Send us the pole diameter of the parasol you intend to use and we will confirm it passes through the opening cleanly.
  • The table holds the pole; the base holds the canopy. A parasol stands on its own weighted base on the ground, with the tabletop only keeping the pole upright and centred. Match that base to the canopy size you plan to fit — an undersized base under a wide canopy is the most common way a shade arrangement fails on a windy day.
  • Shade without losing the accessible bay. Because the pole runs down the centre, the open side of the table stays clear when the parasol is up. A wheelchair user keeps the same approach and the same gap to the nearest seat, whether or not the site has shade in place.
  • Cantilever parasols for the clearest layout. Where a project wants the tabletop completely free of a pole, an offset or cantilever parasol stands beside the table and reaches over it. Check the reach against the footprint so the canopy covers the seats as well as the table edge.
  • Wind, anchoring and the extra sail area. A parasol adds height and surface above the table, so on exposed ground the unit should be fixed down — expansion screws into an existing slab, or embedded fixings cast into new concrete. Take the canopy down or close it when a storm is forecast; the table stays where it is placed, the parasol is what moves.
  • Pairing with the rest of a scheme. Benches, litter bins and planters from the same coating line in the same green keep a shaded seating point looking designed rather than assembled from several suppliers. If the parasols are being bought locally, give us the canopy colour and we can match the top coat to it.
  • Off-season handling. The table stays out all year; the parasol fabric does not. Take the canopy off and store it dry over winter, wipe the pole and base before re-fitting in spring, and leave the centre opening to drain whatever the weather throws at it.
  • What to confirm before ordering. Tell us the parasol model, pole diameter and base type, and whether the tables will be free-standing or anchored, and we will check that the whole set works together. Parasols and bases can be quoted alongside the tables — ask your contact.

Specifications

ModelTB12
Tabletop46" diameter, 2" thick
Tabletop material2.5–3.0 mm perforated steel or metal mesh
Overall footprint81"L x 63.5"W x 30.5"H
Seat size38.5"L x 11.5"W x 18"H, 2" thick
Space between seats15"
Seating configurations2, 3 or 4 seats
Weight, table only220 lbs
Weight, table with seats225 lbs
Frameφ42 x 2.5 mm welded steel pipe
Frame finishBlack DuPont outdoor powder coating
Top and seat finishGreen thermoplastic coating
Fixings304 stainless steel screws
MountingEmbedded or expansion-screw fixing
Green ADA Compliant Metal Mesh Picnic Table with Drainage DesignGreen ADA Compliant Metal Mesh Picnic Table with Drainage Design

Thermoplastic Coating Colors

Green is the standard finish on this model, and it is the reason the table settles into a park rather than shouting across it. The colour is not paint: it is a thick thermoplastic layer fused onto the steel and formulated with UV inhibitors, so it holds its tone through strong sun instead of chalking out after a season.

As an outdoor picnic table supplier working with project teams, we build to a colour brief rather than only to a stock list. If your scheme calls for a different green, a blue that matches the playground equipment, or a tone tied to a municipal palette, the top and seats can be coated to that specification. The frame stays black whatever you choose, which keeps the contrast clean.

Choosing a colour for a site

Colours read differently at scale. One green table in a courtyard looks calm; forty along a trail read as a bright ribbon, which may or may not be what the landscape architect wants. Ask to see a coated sample outdoors, in the light the site actually gets, before you sign off a large run — screens lie about green more than any other colour.

Ordering the whole run at once is the practical way to keep the colour consistent. Coating is matched from batch to batch, and a single production run removes any question of one delivery sitting slightly greener than another. Give us the full quantity and the site phasing at the start and we will plan the run around it.

Green ADA Compliant Metal Mesh Picnic Table with Drainage Design

Installation & Anchoring

  1. Unpack and check the delivery against the packing list: tabletop, seat panels, welded frame, the bag of 304 stainless screws and the assembly instructions.
  2. Set the metal picnic table on the prepared pad and check that it sits level before anything is fixed down.
  3. Choose the mounting method. Free-standing suits sites that rearrange seating seasonally; expansion screws suit an existing concrete slab; embedded fixings are cast into new concrete while it is being poured.
  4. Bolt the seat panels to the frame with the supplied screws, working around the table so the panels pull down evenly. Two people make this quick.
  5. Fix through the pre-drilled mounting points, tightening in rotation rather than one corner at a time.
  6. Check the finished table: seats level, no rocking, the open bay clear, and the centre opening free for a parasol pole.

Ordering & Delivery

Orders start at 10 units per item, and the exact minimum depends on the product and the configuration — a run of green two-seat tables is a different proposition from a mixed consignment of tables, benches and bins. Lead time depends on the product as well and runs from 10 days upward, so build that into your programme before you fix an installation date. As your outdoor picnic table supplier we ship direct from the factory, which means the unit you receive is the unit we coated. Tell us the delivery address and the site access in advance and we will confirm how the goods will be packed and unloaded. Three things to settle before the order is placed: the colour, the number of seats, and whether the tables will be free-standing, expansion-bolted or embedded. Get those right and delivery is straightforward. If you need to see the finish before committing, ask your sales contact about sample availability. On phased projects, give us the whole schedule at the start — one planned production run is easier to keep consistent than three separate ones.

Scale & Supply Capability

Arlau is a manufacturer, not a middleman: Chongqing Arlau Civic Equipment Manufacturing Co., Ltd has been producing outdoor furniture and public facilities since 1999, more than 26 years in the trade. Our 13,000 sqm factory runs a fully automatic robot production line with an annual output of 130,000 pieces, and a 100-person team covers production, export paperwork and after-sales follow-up. Goods ship to more than 80 countries and regions. OEM/ODM one-stop export service is handled in-house, so you keep one contact from drawing to delivery.

FAQ

What ADA guidelines does this picnic table meet?

The layout is built around the three things a wheelchair user needs at a table: knee clearance, an approach route and a usable surface height. On this metal picnic table that means a 30.5-inch tabletop with an open underside, a clear bay on one side with no bench in front of it, and a 15-inch gap between the seats so a chair can pull in beside a companion. Seat height is 18 inches, which is also a workable transfer height for many users. Final compliance is decided by the authority your project answers to, and clear floor space requirements around the table vary between them. Send us your accessibility schedule and we will check the dimensions against it before you commit.

Why is a metal mesh top better than a solid tabletop outdoors?

Because it does not hold water. Rain falls through the perforations instead of sheeting across the surface, so the table is dry and usable sooner after a storm, and leaves and grit drop through rather than collecting in the middle. Nothing stands long enough for algae or mould to get started, which cuts both cleaning and the slip risk on a wet seat. A solid top also bakes in direct sun, whereas the thermoplastic coating on this all weather outdoor picnic table is formulated to disperse heat so the surface stays comfortable when the sun is high. The one trade-off is that a mesh top wants a firm, flat pad underneath, since small items can fall through the openings.

Can we have this 46 inch picnic table in a different colour?

Yes. Green is the standard thermoplastic finish for this model, but the top and seats can be coated to another colour when a project needs it. Send a reference — a RAL or Pantone number, a photograph of the surrounding furniture, or the palette the site has to follow — and we will confirm the closest match from the coating range. The frame stays black whichever colour you choose. Look at a physical sample outdoors before approving a large run: green in particular shifts a long way between a screen and a park in late afternoon light.

Does the table arrive assembled, and how is it installed?

It arrives partly assembled and needs some straightforward on-site work: the seat panels go onto the frame with the supplied 304 stainless screws, and the instructions and hardware travel with the unit. Two people make it quick. For a permanent installation the table is fixed through pre-drilled mounting points — expansion screws into an existing concrete slab, or embedded fixings cast into new concrete. This heavy duty picnic table can also be left free-standing on a firm pad where seating has to move for events or seasonal layouts. Whichever route you take, set it on level ground and check for rocking before the fixings are tightened.

What makes this table a practical choice for a public project?

It removes most of the recurring cost of outdoor seating. The coating is the finish, so there is no repainting programme; the perforated surfaces drain and dry without staff going out with a cloth; the stainless fixings do not seize; and the open bay means the same table serves wheelchair users and everyone else instead of requiring a second accessible unit. As a commercial picnic table manufacturer we also supply the documentation a tender asks for, with ISO9001, ISO14001 and ISO45001 management systems and CE conformity behind the product.

Is there a hole for an umbrella or parasol?

Yes — there is an opening through the centre of the round tabletop. A parasol pole passes through it and stands on its own base; the tabletop supports the pole, not the canopy, so choose a weighted base rated for the parasol you intend to use. That keeps the centre of the table clear and gives a site an easy way to add shade without a separate structure.

How many people can sit at the table?

It depends on the configuration you order, because the table is built with two, three or four seats. With two seats fitted, two people sit at the table and the open bay takes a wheelchair user alongside them; adding seats increases capacity and uses up part of that open bay. A four-seat version is the choice where general seating matters most, and a two-seat version is the choice where accessibility comes first. Each seat is 38.5 inches long and 11.5 inches deep, and there are 15 inches between the seat ends.

Can the table be moved once it is on site?

A free-standing unit can be moved. At 220 lbs for the table alone and 225 lbs with the seats on, it is a two-person job with a hand truck and a clear route rather than something one person lifts — realistic for seasonal rearrangement, repaving work or clearing a table for an event. Once it is bolted to a slab or set on embedded fixings it stays where it is put, so if you expect to move seating regularly, order this round steel picnic table free-standing and anchor only the units that need to resist theft or wind.
